Article group: 431
BI-METAL
SPRINT-PLUS
- Classic tooth geometry to suit all your generalpurpose needs
- Variable tooth design for a wider range of material sizes
- M42 HSS tooth tip for long and reliable performance
Original price was: $10.00.$8.00Current price is: $8.00.Select options This product has multiple variants. The options may be chosen on the product page
Delivery program
| Dimensions | Tooth | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| mm | inch | 0,75/1,25 | 1,4/2 | 2/3 | 3/4 | 4/6 | 5/8 | 6/10 | 8/12 | 10/14 | 14 | 18 |
| 20 × 0,90 | 3/4 × .035 | ■ | ■ | ■ | ■ | ■ | ■ | ■ | ||||
| 27 × 0,90 | 1 × .035 | ■ | ■ | ■ | ■ | ■ | ■ | ■ | ■ | |||
| 34 × 1,10 | 1 1/4 × .042 | ■ | ■ | ■ | ■ | ■ | ■ | ■ | ■ | |||
| 41 × 1,30 | 1 1/2 × .050 | ■ | ■ | ■ | ■ | ■ | ||||||
| 54 × 1,30 | 2 × .050 | ■ | ■ | ■ | ||||||||
| 54 × 1,60 | 2 × .063 | ■ | ■ | ■ | ||||||||
| 67 × 1,60 | 2 5/8 × .063 | ■ | ||||||||||
| 80 × 1,60 | 3 × .063 | ■ | ■ | |||||||||
Your solution for a wide range of applications.
Our SPRINT-PLUS Band Saw Blade is engineered for diverse industrial applications, catering to the precise needs of medium to large workpieces across all metals. Produced from robust materials, it offers seamless performance in single or bundle cutting applications, delivering amazing flexibility.
Key features
- Variable and constant tooth pitch
Offers flexibility with both constant and variable tooth pitch options, meeting diverse cutting requirements.
- Positive or neutral rake angle
Ensures long-lasting performance thanks to precision and high-quality materials.
- Precision Engineering
Ensures high precision in strip straightness and consistency, guaranteeing optimal results.
Frequently asked questions
What is a bi-metal Band Saw Blade?
Bi-metal Band Saw Blades combine the high flexibility of the base band, made of specially alloyed heat-treated steel with the enormous resistanceof the tooth tips made of hardened and tempered high-speed steel (HSS) in the qualities M42 and M51.
Why do Band Saw Blades need to be retracted?
It is always recommended to run in the Band Saw Blades when using them for the first time to prevent premature tooth edge breakage. This significantly changes the service life and cutting quality of the Band Saw Blade.
What does tooth pitch mean?
The tooth pitch refers to the distance between the individual tooth tips on the saw blade and is measured in teeth per inch (ZpZ). A larger tooth pitch means a greater distance between the tooth tips, while a smaller tooth pitch means a narrower distance between the tooth tips. For optimum sawing results, the correct tooth pitch should be always ensured.
What dimension of Band Saw Blade do I need?
The dimension of the Band Saw Blade is determined by the model of the band saw and is given in millimeters (or inches). Please take this information from the machine manufacturer’s specifications. ARNTZ Band Saw Blades can be individually made to measure for you or supplied as coils.
What is the difference between constant and variable tooth pitch?
With constant tooth pitch, all tooth tips have a constant distance to each other. With variable tooth pitch, the distances vary within a toothing interval.
